Configurations

Generalities

Configurations define settings for PCVS. There are 5 basic configurations files which are:

compiler
criterion
group
machine
runtime

One of each configuration are used to build a profile. The profile is the top level configuration used to run pcvs.

Scope

PCVS allows 3 scopes:

local accessible only from a specific .pcvs folder.
The local folder is defined as the first .pcvs folder found walking up the file system tree from the execution directory of pcvs.
user accessible from everywhere for the corresponding user, store in ~/.pcvs
global for everyone on the machine having access to the PCVS installation.
global configuration are read only, they are stored in the pcvs installation and override at each pcvs install. This scope is used to ship default configurations that can be used directly or as template for creating your own configuration in user or local scope.

Command usage

To list existing configurations, use the command:

$ pcvs config list

To create a config, one can use the command:

$ pcvs config create user:example_profile

By default, the new configuration will contain the default configuration block for your configuration type. To copy from another configuration block, use:

$ pcvs config create --clone global:compiler:gcc user:compiler:mygcc

This configuration is fully customizable with any text editor, to edit the configuration, use the command:

$ pcvs config edit profile:example_profile

To export or import configuration, use the command:

$ pcvs config export profile:default --output test.yml
$ pcvs config import user:profile:default_copy --source test.yml

To delete a configuration, use the command:

$ pcvs config destroy <configuration_name>

Files architecture

For each storage scope, configurations are stored in files in a tree like structure and can be edited manually for automation.

Warning

When edited manually, pcvs will not be able to check and validate your configuration. Using pcvs config edit is preferred.

~/.pcvs
├── compiler
│   ├── default.yml
│   ├── gcc.yml
│   └── mpi.yml
├── criterion
│   ├── default.yml
│   └── mpi.yml
├── group
│   ├── common.yml
│   └── default.yml
├── machine
│   ├── default.yml
│   └── slurm.yml
├── plugin
│   ├── default.py
│   └── mpi.py
├── profile
│   ├── default.yml
│   ├── gcc.yml
│   └── mpi.yml
└── runtime
    ├── default.yml
    └── mpi.yml

Profile

A PCVS profile is the root configuration block that link all configurations together and need to be provided to pcvs to run a test suite. A profile contain 5 references, to one of each of the configuration types. It will look like that:

compiler: local:gcc
criterion: global:default
group: default
machine: mycluster.yml
runtime: default

Scopes can be optionally provided. If not provided, all scope are check in order local -> user -> global. File extensions are optionnals.

Configuration description

Compilers configuration

The compiler configuration describes how to use a compiler, it includes the following nodes:

program: the name of the program to execute
envs: the env to export at build time for that compiler, useful if you are using a Makefile
extension: the source code extension match by the compilers.
variants: different version of the same compiler configuration entry.

Compilers example

The compiler.compilers block contains a collection of compiler configurations. The scheme is explained in the following

compilers:
   <name>:
      program: "Name of the executable"
      args: ["Arguments", "to", "pass", "to", "the", "compiler"]
      envs: ["Environment", "variables", "to", "set", "when using the compiler"]
      type: "Default set of extensions to use on"
      extension: "Regex describing the extension of the file on which the compiler should be used"
      # Variants are optional sets of arguments and environment variables
      # Some tests use those variants to have an agnostic way to influence the build
      variants:
         <name>:
            program: "Name of the executable"
            args: ["Arguments", "to", "pass", "to", "the", "compiler"]
            envs: ["Environment", "variables", "to", "set", "when using the compiler"]

The default compilers configuration may look like the following example

compilers:
  cc:
    program: mpicc
    envs: [PCVS_CC=mpicc]
    extension: "\\.(h|H|i|I|s|S|c|c90|c99|c11)$"
    variants: &openmp
      openmp:
        args: [-fopenmp]
  cxx:
    program: mpicxx
    envs: [PCVS_CXX=mpicxx]
    extension: "\\.(hpp|C|cc|cxx|cpp|c\\+\\+)$"
    variants: *openmp
  f77:
    program: mpif77
    envs: [PCVS_FC=mpif77]
    extension: "\\.(f|F)(77)?$"
    variants: *openmp
  f90:
    program: mpif90
    envs: [PCVS_FC=mpif90]
    extension: "\\.(f|F)(90)?$"
    variants: *openmp
  fc:
    program: mpifort
    envs: [PCVS_FC=mpifort]
    extension: "\\.(f|F)(95|(20)?(03|08)|c)?$"
    variants: *openmp

Variants

The variants block can contain any custom variant. The variant must have a name, and arguments as such:

example_variant:
    args: additional arguments for the example variant
openmp:
    args: [ '-fopenmp' ]
    envs: [ 'PCVS_CFLAGS="-fopenmp"' ]
strict:
    args: [ '-Werror', '-Wall', '-Wextra' ]

In this example the variants “example_variant”, “openmp”, and “strict” have to be specified in the validation setup where the user wants to use them.

Note

If multiple variants are requested by a test, the args and envs will be concatenated. Multiple variants does not produce multiple build configuration, you have to use different jobs for this purpose

Criterion configuration

The criterion configuration contains a collection of iterators that describe the tests. PCVS can iterate over custom parameters as such :

<name> :
    <iterator> :
        subtitle : "String used to indicate the number of <iterator> in the test description"
        values : ["Values that <iterator>", "is allowed to take"]

Example

criterions:
    n_core:
        subtitle: C
        values: [1, 2]

In this case the program has to iterate on the core number and has to take the values 1 and 2. The name n_core is arbitrary and has to be put in the validation setup file.

Series

When iterators are declared as numeric by the runtime, special syntaxes have been introduced to ease the definition of series of number. These are called sequences and can be used as a replacement of a single value. They map as dict instead of a single value. There is 3 types of sequences:

sequence | arithmeric: to create an arithmetic sequence: U(n+1) = U(n) + k.
multiplication | geometric: to create a geometric sequence: U(n+1) = U(n) * k.
powerof: to create a list within a range where values are power of k.

Each operation comes with three parameters:

from: lowerbound (inclusive)
to: upperbound (inclusive)
of: the stride/factor/power to apply
op: type of operation:
- seq | ari | arithmetic
- mul | geo | geometric
- pow | powerof

Series Examples

{op: seq, from: 2, to: 10, of: 2} –> [2, 4, 6, 8, 10]
{op: mul, from: 1, to: 100, of: 2} –> [1, 2, 4, 8, 16, 32, 64]
{op: pow, from: 2, to: 10, of: 2} –> [4, 9] == [2^2, 3^2]
{op: pow, from: 1, to: 100, of: 3} –> [1, 8, 27, 64] == [1^3, 2^3, 3^3, 4^3]

Group configuration

The group configuration contains group definitions that describe tests. A group description is a test template that can contain any node present in the Test Configuration. (cf. Test Specification)

Example

The following scheme shows how group can be used to inherit part of the criterion and to restrict other.

<group_name>:
    # We can restrict some iterators
    run:
        iterate:
            # inherit whitelists the criterions to use
            # if not defined, all the criterions are applied
            inherit: ["Criterions", "to", "use", "as defined in the criterions configuration"]
            <iterator_name>:
                values: ["possible", "values"]

Machine configuration

The machine configuration describes the constraints of the physical machine.

machine:
    nodes: 2               # number of accessible nodes
    cores_per_node: 12     # number of accessible cores per node
    concurrent_run: 4      # maximum number of processes that can coexist
    build_job_threads: 1   # default number of workers for concurrent building (i.e. make -j)
    # Machine level resource manager configuration
    job_manager:
        # Configuration of the allocation command
        allocate:
            program: 'salloc' # name of the executable to allocate resources
            args: ['-p partition'] # list of args to pass to the allocation command
            wrapper:
        # Configuration of the run command
        remote:
            program: 'srun' # name of the executable to launch on allocated resources
            args: ['-p partition'] # list of args to pass to the launch command
            wrapper:
        # Configuration of the run in batch command
        batch:
            program:
            args:
            wrapper:

Runtime configuration

program specify a wrapper for runtime tests, such as mpirun for example. The compiling.wrapper specify a wrapper for test compilation. It can be used to run the compilation on another node using srun for example.

The criterions configuration contains arguments passed to the launching command. For example, if prterun takes the “-np” argument, which corresponds to the number of MPI threads, let’s say n_mpi, we will get the following runtime profile:

plugins specify a python plugin that will be loaded and use to filter available criterions. defaultplugin specify the name of one of the default plugin to use.

args specify static arguments to program.

program:
compiling:
  wrapper:
args:
plugin:
defaultplugin:
criterions:
    n_mpi:
        numeric: true
        option: "-np"
        type: argument
        aliases:
            [dictionary of aliases for the option]

Plugin

Runtime reference a plugin configuration. The plugin configuration is a python plugin with a function to filter valid criterions.

Warning

When cloning a plugin with pcvs create --clone make sure to rename the Class in the plugin. Otherwise, only one of the 2 plugins with the same name will be loaded.
